JARRAFF 4 wheel drive

JARRAFF 4 wheel drive

Most versatile configuration for a variety of terrains.

Power

Power

Stage IV - 97 kW / 130 HP

Stage IV - 97 kW / 130 HP

Weight

Weight

24,820 lbs

11,258 kg

Ground pressure

Ground pressure

6.7 psi

0.46 kg/cm2

Your Benefits

Maximum Efficiency

Maximum Efficiency

For forest service providers it is the most efficient and economical method of felling trees compared to alternative methods: less labour & higher productivity.

Fast & Precise

Fast & Precise

Precision cutting with a rotating saw head to achieve all angles even at maximum height. A quick through cut action prevents peeling backs and hanging limbs.

Maximum Safety

Maximum Safety

ROPs /FOPs certified cab provides the operator with the highest level of safety. ANSI 92.2 Category C dielectric compliance gives safety around power lines.

The smarter way to trim trees

The smarter way to trim trees

Fast. Safe. Efficient.

Maximize work safety and more productivity compared to conventional methods. Eliminate the need for power shutdowns while trimming vegetation.

Features

180° rotatable 610mm carbide-tipped saw blade at 3,000 RPM.

Telescoping di-electric fiberglass boom for a max operating height of up to 23 m. ANSI 92.2 Category C dielectric compliance provides additional safety around power lines.

Reliable Cummins engine
(Tier-4f 97 kW/130 HP)
(Stage V 100 kW/134 HP)

The user passcode display offers push-to-start and important operating and engine monitoring in real-time.

Foot pedal and joystick operation.

Clears trimmed material and aides in stability in difficult terrain.

20,000 lb. rear-mounted recovery winch. An additional front-mount winch is optional.

Technical data

  • Power

    Stage IV - 97 kW / 130 HP

    Stage IV - 97 kW / 130 HP

  • Weight

    24,820 lbs

    11,258 kg

  • Ground pressure

    6.7 psi

    0.46 kg/cm2

  • Total width

    Max. 10 ft, 4 in

    2.62 – 3.15 m

  • Total length

    41 ft, 6 in

    12.65 m

  • Travel Speed

    12.4 mph

    20 km/h

  • Working range

    0-75ft

    0- 23 m

  • Saw blade

    Ø 610 mm cuts at 3.200 min

    Ø 610 mm cuts at 3.200 min

  • Saw blade rotation

    180°

    180°

  • Tire size

    28 L x 26

    28 L x 26

  • Transmission

    Hydraulic transmission

    Hydraulic transmission

  • Boom with cabin

    360° rotation & 35° swiveling sidewise

    360° rotation & 35° swiveling sidewise
