OX R700m

OX R700m

Can be used both as a subsoiler and as a stump grinder.

Power

Power

100-240 HP
100-240 HP
Working width

Working width

25.6 in
650 mm
Working depth

Working depth

9.8 in
250 mm

Your Benefits

Perfect shredding

Perfect shredding

The patented tool system ensures perfect shredding of roots and root remains and their mixing into the subsoil.

Robust and safe

Robust and safe

A strong and robust housing made of durable steel is ideal for applications with intensive ground contact. The hydraulic hoses are protected inside the housing.

Versatile rotavator

Versatile rotavator

With a cutting depth of up to 30 cm (11.8 in) and the option of rotating the rotor backwards, it covers a wide range of uses. It can be used for mulching too.

A multipurpose machine for tractors, Ideal in plantations

The OX R700m is for tractors in the power class of 100 - 240 HP. It mulches roots and stumps and works the biomass into the soil to a depth up to 25 cm. This machine can be used universally and is suitable for shredding roots and root residues and working them into the subsoil. It is ideal for row subsoiling in plantations.

Features

The rotor is driven by 6-grooved spring-tensioned power belts.

Mounting to tractors is done with a 3-point power hitch CAT II and CAT III.

Height adjustable and wear resistant deep milling skids are easy exchangeable.

Rotor available with HDT tools. Maximum reliability, built against highest impacts and loads.

The housing is equipped with bolted liners with counter blades. The liners are made out of highly wear-resistant steel and are easy exchangeable.

The chain curtain provides extra protection while mulching.

Supporting legs are available for a stable and safe stand on the ground and during transport.

The protection flap guides the material to the ground. It is easy to adjust by a chain.

The post compacting roller is adjusted by a hydraulic cylinder. This allows to adjust the milling depth. The wiper is adjustable in height for roller with a raised roll, the tools can easily switch.

The patented W-Kinematic keeps the angles equal to prevent damage to the PTO shaft and supports an ideal adaptation to the conditions of the ground for an optimal lifting height.

With the spring tension, the drive belts are in an optimum tension ratio and transmit the forces in the best possible way.

Technical data

Download (PDF)
  • Power

    100-240 HP
    100-240 HP
  • Working width

    25.6 in
    650 mm
  • Working depth

    9.8 in
    250 mm
  • Total width

    46.1 in
    1,170 mm
  • Weight

    3,682 lbs
    1,670 kg
  • Rotor diameter

    27.6 in
    700 mm
  • Tools

    16 x HDT
    16 x HDT
